NOTE
▶Free shipping with AliExpress standard logistics, faster delivery.
▶This panel remote control is suitable for all RF433Mhz receiving modules in our store (not self-matched), so you can use this product with more types of receivers. If you have any questions about use, please feel free to contact us and we will be happy to answer you. Thanks.
Product Advantages
●Without Neutral Wire
Single live wire,No need for neutral wires
●Simple wiring & Support 2-way control
The product comes with two small lines,Simple wiring and easy installation.Support two-way control, suitable for more scenarios.
●Mini Body
It can be directly installed in the switch bottom box, which is more convenient for maintenance and installation.
●RF 433Mhz wireless remote control
After installation, the previous traditional switch can still be used, at the same time, the switch has added a wireless remote control function,A receiver supports about 20pcs panels control.
●Long Conrol Distance
Open space is more than 50 meters.
●Suport Flexible Pairing
No interference to use several in the same room, One receiver can be stably paired with up to 20 wireless panel switches.
*One 2-in-1 wireless panel switch control 2 receivers.
*Multiple wireless panel switches to control one receiver.
●Magnetic Separation Design
The switch can be removed from the base and turned into a remote control, making it convenient for the elderly and children to control the light switch. It can also be attached to metal objects (such as refrigerator doors). The base can be attached to the wall using double-sided tape (included) or screws (included).
●Low Power Consumption, Long Service Life
The panel switch key life is 100,000 times. The switch is very energy efficient. Using 2pcs CR2016 batteries (included), they can be used normally for more than 7000 times.
Comprehensive after-sales and service
√ This product has passed CE and RoHS and FCC certification.
√ 1 year warranty or replacement commitment.
√ Our after-sales service team can provide the most professional solution to any of your problems.
Features
●Simple wiring & Support 2-way control
The product comes with two small lines,Simple wiring and easy installation.Support two-way control, suitable for more scenarios.
★★★The product comes with a safety capacitor. When the controlled lamp is slightly bright or flashing,
a safety capacitor should be added between the “N” line and “L” line of the lamp (as shown in the figure).
▼RF433MHz Wireless Remote Control▼
Control lights with your RF433 remote or the previous traditional switch without a network,Smarter than traditional control,Simpler and suitable for the elderly.
●Long Conrol Distance
Open space is more than 50 meters.
●Suport Flexible Pairing
No interference to use several in the same room, One receiver can be stably paired with up to 20 wireless panel switches.
*One 2-in-1 wireless panel switch control 2 receivers.
*Multiple wireless panel switches to control one receiver.
●Magnetic Separation Design
The switch can be removed from the base and turned into a remote control, making it convenient for the elderly and children to control the light switch. It can also be attached to metal objects (such as refrigerator doors). The base can be attached to the wall using double-sided tape (included) or screws (included).
Parameter
▶RF 433Mhz MiniRelay Receiver :
Working voltage : AC 100-240V 50/60HZ.
Max Load :150W.
RF Frequency: 433MHz.
Receiving Distance : up to 50m (theoretical distance).
Code :1527 learning or 2262 fixed.
Working temperature: -30 ~ +80
Size: 42*42*23 mm.
Work with remote : Can be controlled by 20pcs remotes.
Appliance : LED,Lamp,Ceiling Light,Crystal Light,Wall lamp,floor lamp,etc.
▶ RF433mhz Wireless Wall Panel Switch
Feature:Panel can be magnetically attached to the base
Support encoding : 1527 Leaning code
RF frequency : 433MHz
Size: 80*60*15 mm
Battery : CR2016*2( Included)
Screw: Included
Double-sided tape: Included
Base:Included
How to pair and clear signals
★Make the following settings in the power-on state.
▶How To Pair 433Mhz Signals:
Step1:Press the learning button 2 times . Wait for 3 seconds;
Step2: Press the button on the panel switch 1 time ,Succeed.
▶How To Clear 433Mhz Signal:
Only one step :Press the learning button 8 times. Wait for 3 seconds;
▶Please contact with us if you have any questions.Thank you.
▶We have own factory,if you want to do ODM OEM bussiness,please contact with us.
